Breve Análise do Portátil Asus F551MA-SX063H

Frugal. O F551MA não trás muito poder de desempenho. Porém, ganha pontos com o seu baixo consumo de energia e baixas emissões. Será isto suficiente contra a concorrência no segmento de preços mais baixos?
247
cd/m²
248
cd/m²
231
cd/m²
251
cd/m²
241
cd/m²
238
cd/m²
240
cd/m²
234
cd/m²
236
cd/m²
Distribuição do brilho
ChiMei N156BGE-L21 tested with X-Rite i1Pro 2
Máximo: 251 cd/m² (Nits) Médio: 240.7 cd/m²
iluminação: 92 %
iluminação com acumulador: 244 cd/m²
Contraste: 301:1 (Preto: 0.8 cd/m²)
ΔE Color 4.7 | 0.5-29.43 Ø5
ΔE Greyscale 4.56 | 0.57-98 Ø5.3
56% AdobeRGB 1998 (Argyll 2.2.0 3D)
81.6% sRGB (Argyll 2.2.0 3D)
54.2% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.84
Cinebench R11.5 CPU Single 64Bit
0.44 Points
Cinebench R11.5 CPU Multi 64Bit
1.75 Points
Cinebench R11.5 OpenGL 64Bit
6.53 fps
Cinebench R15 CPU Single 64Bit
38 Points
Cinebench R15 CPU Multi 64Bit
128 Points
Cinebench R15 OpenGL 64Bit
4.08 fps
Cinebench R15 Ref. Match 64Bit
97.8 %
Ajuda
Cinebench R11.5 - CPU Single 64Bit (sort by value)
Asus F551MA-SX063H
HD Graphics (Bay Trail), N3520, Western Digital Scorpio Blue WD5000LPVX
0.44 Points
HP Compaq 15-h024sg
Radeon HD 8210, E1-2100, Toshiba MQ01ABF050
0.23 Points -48%
Medion Akoya E6239T
HD Graphics (Bay Trail), N3510, Seagate Momentus SpinPoint M8 ST1000LM024 HN-M101MBB
0.38 Points -14%
Acer Aspire E1-532
HD Graphics (Haswell), 2955U, Seagate Momentus Thin ST500LT0 12-9WS142
0.61 Points +39%
Lenovo G500s-59367693
HD Graphics (Ivy Bridge), 2020M, Seagate Momentus Thin ST500LT0 12-9WS142
1 Points +127%
Cinebench R11.5 - CPU Multi 64Bit (sort by value)
Asus F551MA-SX063H
HD Graphics (Bay Trail), N3520, Western Digital Scorpio Blue WD5000LPVX
1.75 Points
HP Compaq 15-h024sg
Radeon HD 8210, E1-2100, Toshiba MQ01ABF050
0.46 Points -74%
Medion Akoya E6239T
HD Graphics (Bay Trail), N3510, Seagate Momentus SpinPoint M8 ST1000LM024 HN-M101MBB
1.47 Points -16%
Acer Aspire E1-532
HD Graphics (Haswell), 2955U, Seagate Momentus Thin ST500LT0 12-9WS142
1.14 Points -35%
Lenovo G500s-59367693
HD Graphics (Ivy Bridge), 2020M, Seagate Momentus Thin ST500LT0 12-9WS142
1.94 Points +11%
PCMark 7 Score
1790 pontos
Ajuda
PCMark 7 - Score (sort by value)
Asus F551MA-SX063H
HD Graphics (Bay Trail), N3520, Western Digital Scorpio Blue WD5000LPVX
1790 Points
HP Compaq 15-h024sg
Radeon HD 8210, E1-2100, Toshiba MQ01ABF050
1051 Points -41%
Acer Aspire E1-532
HD Graphics (Haswell), 2955U, Seagate Momentus Thin ST500LT0 12-9WS142
1484 Points -17%
Medion Akoya E6239T
HD Graphics (Bay Trail), N3510, Seagate Momentus SpinPoint M8 ST1000LM024 HN-M101MBB
1678 Points -6%
Lenovo G500s-59367693
HD Graphics (Ivy Bridge), 2020M, Seagate Momentus Thin ST500LT0 12-9WS142
2343 Points +31%
Western Digital Scorpio Blue WD5000LPVX
Sequential Read: 106.3 MB/s
Sequential Write: 104.1 MB/s
512K Read: 40.69 MB/s
512K Write: 57.1 MB/s
4K Read: 0.531 MB/s
4K Write: 1.593 MB/s
4K QD32 Read: 1.33 MB/s
4K QD32 Write: 1.605 MB/s
3DMark 11 Performance
261 pontos
3DMark Ice Storm Standard Score
20652 pontos
3DMark Cloud Gate Standard Score
1515 pontos
Ajuda
3DMark 11 - 1280x720 Performance (sort by value)
Asus F551MA-SX063H
HD Graphics (Bay Trail), N3520, Western Digital Scorpio Blue WD5000LPVX
261 Points
Medion Akoya E6239T
HD Graphics (Bay Trail), N3510, Seagate Momentus SpinPoint M8 ST1000LM024 HN-M101MBB
240 Points -8%
HP Compaq 15-h024sg
Radeon HD 8210, E1-2100, Toshiba MQ01ABF050
369 Points +41%
Lenovo G500s-59367693
HD Graphics (Ivy Bridge), 2020M, Seagate Momentus Thin ST500LT0 12-9WS142
390 Points +49%
Acer Aspire E1-532
HD Graphics (Haswell), 2955U, Seagate Momentus Thin ST500LT0 12-9WS142
480 Points +84%
baixo média alto ultra
Dirt 3 (2011) 36.9 13.3
Counter-Strike: GO (2012) 46.6 23.9
Dishonored (2012) 14.3 11.2
Dead Space 3 (2013) 23.6 9.7
Tomb Raider (2013) 15.5 8.1
Battlefield 4 (2013) 7.3
Thief (2014) 5.1 3.3
The Elder Scrolls Online (2014) 25.2 9.2
Asus F551MA-SX063H
HD Graphics (Bay Trail), N3520, Western Digital Scorpio Blue WD5000LPVX
Acer Aspire E1-532
HD Graphics (Haswell), 2955U, Seagate Momentus Thin ST500LT0 12-9WS142
Lenovo G500s-59367693
HD Graphics (Ivy Bridge), 2020M, Seagate Momentus Thin ST500LT0 12-9WS142
Tomb Raider
86%
43%
1024x768 Low Preset
15.5
30.3
95%
23.1
49%
1366x768 Normal Preset AA:FX AF:4x
8.1
14.3
77%
11.1
37%

Barulho

Ocioso
30.4 / 30.4 / 30.4 dB
HDD
30.6 dB
DVD
36.3 / dB
Carga
31.7 / 36.2 dB
  red to green bar


30 dB
silencioso
40 dB(A)
audível
50 dB(A)
ruidosamente alto

min: dark, med: mid, max: light   Voltcraft sl-320 (15 cm de distância)
Inatividade
 32.7 °C28 °C27.7 °C
 31.8 °C28 °C27.2 °C
 30.9 °C29.1 °C30.6 °C
Máximo: 32.7 °C
Médio: 29.6 °C
28.8 °C28.5 °C33.6 °C
28.6 °C28 °C31.6 °C
30.7 °C27.7 °C30.2 °C
Máximo: 33.6 °C
Médio: 29.7 °C
alimentação elétrica  38.2 °C | Temperatura do quarto 23.7 °C | Voltcraft IR-360
(+) The average temperature for the upper side under maximal load is 28.1 °C / 83 F, compared to the average of 29.5 °C / 85 F for the devices in the class Office.
(+) The maximum temperature on the upper side is 33.2 °C / 92 F, compared to the average of 34.2 °C / 94 F, ranging from 21.2 to 62.5 °C for the class Office.
(+) The bottom heats up to a maximum of 30.6 °C / 87 F, compared to the average of 36.7 °C / 98 F
(+) In idle usage, the average temperature for the upper side is 29.6 °C / 85 F, compared to the device average of 29.5 °C / 85 F.
(+) The palmrests and touchpad are cooler than skin temperature with a maximum of 30.9 °C / 87.6 F and are therefore cool to the touch.
(-) The average temperature of the palmrest area of similar devices was 27.7 °C / 81.9 F (-3.2 °C / -5.7 F).
Consumo de energia
desligadodarklight 0 / 0.3 Watt
Ociosodarkmidlight 5 / 8 / 8.6 Watt
Carga midlight 16.5 / 21.6 Watt
 color bar
Key: min: dark, med: mid, max: light        Voltcraft VC 940
Currently we use the Metrahit Energy, a professional single phase power quality and energy measurement digital multimeter, for our measurements. Find out more about it here. All of our test methods can be found here.
Tempo de Execução da Bateria
Navegar com WLAN
4h 16min

Com o F551MA-SX063H, a Asus oferece um portátil de escritório simples, que somente é adequado para tarefas simples. O portátil somente precisa de um pouco de energia e sempre funciona silenciosamente. Além disso, a duração da bateria é boa em nosso teste realista de WLAN. A tela nos surpreendeu: Ela é bastante brilhante e suas cores são boas, mas o seu contraste é baixo e tem ângulos de visão estreitos.

Se o preço for um critério importante, o Aspire E1-532 é a melhor alternativa: O desempenho de sua CPU é melhor em aplicativos single-thread, e tem uma GPU mais poderosa. Além disso, sua duração de bateria é mais longa, e funciona de forma tão silenciosa quanto o F551MA. Além disso, a tela é mate e a garantia é de dois anos. O Acer está atualmente disponível por cerca de 270 Euros (~$371). Se você adicionar o custo pela licença do Windows 8.1, o preço do Aspire é de cerca de 350 Euros (~$481), também. Portanto, a relação preço-desempenho do Aspire é significantemente melhor ao do Asus.

Lenovo G500s é a melhor opção se estiver procurando o desempenho de CPU mais alto. Ele custa atualmente cerca de 300 Euros (~$412, sem Windows OS).

Esta é uma versão reduzida da análise original. Você pode ver a análise completa em inglês aqui.

Please share our article, every link counts!

Especificações do portátil

Asus F551MA-SX063H
Processador
Intel Pentium N3520 4 x 2.2 - 2.4 GHz, Bay Trail-M
Placa gráfica
Intel HD Graphics (Bay Trail), Análises do: 820 MHz, 10.18.10.3355
Memória
4 GB
, DDR3, single channel, soldado, sem slots RAM
Pantalha
15.60 polegadas 16:9, 1366 x 768 pixel, ChiMei N156BGE-L21, Brilhante: sim
placa mãe
Bay Trail Host Bridge
Disco rígido
Western Digital Scorpio Blue WD5000LPVX, 500 GB
, 5400 rpm, 408 GB livre
Placa de Som
Intel Valleyview SoC - HD Audio Controller
Conexões
1 USB 2.0, 1 USB 3.0, 1 VGA, 1 HDMI, 1 Kensington Lock, Conexões Audio: Audiokombo, Card Reader: SD
Funcionamento em rede
Realtek RTL8102E Family PCI-E Fast Ethernet (10/100MBit/s), Realtek RTL8821AE 802.11ac (), Bluetooth 4.0
Unidade ótica
Matshita DVD-RAM UJ8E1
Tamanho
altura x largura x profundidade (em mm): 36.6 x 380 x 251
Bateria
33 Wh Lítio-Ion
Sistema Operativo
Microsoft Windows 8 64 Bit
Camera
Webcam: HD web cam
Características adicionais
Alto falantes: Estéreo, Teclado: Chiclet, Iluminação do Teclado: não, AsusDVD, Microsoft Office 365 (versão de teste), Windows Essentials 2012, 12 Meses Garantia
peso
2.15 kg, Suprimento de energia: 137 g
Preço
379 Euro



Portáteis de um fabricante diferente e com CPU diferente

Breve Análise do Portátil Dell Inspiron 15-3531
HD Graphics (Bay Trail), Celeron N2830
Breve Análise do Portátil Lenovo B50-30
HD Graphics (Bay Trail), Celeron N2815
Breve Análise do Portátil Acer Aspire E1-510P-2671
HD Graphics (Bay Trail), Celeron N2920

Portáteis com o mesmo GPU

Breve Análise do Portátil HP 14-r003ng
HD Graphics (Bay Trail), Pentium N3530, 14.00", 1.96 kg

Portáteis com o tamanho de tela e peso

Análise do Asus ExpertBook B3: O poderoso laptop de escritório com autonomia de 11 horas
GeForce RTX 2050 Mobile, Raptor Lake-U i7-1355U, 14.00", 1.653 kg
Análise do laptop para estudantes Asus BR1402FG: Robusto para o uso diário
UHD Graphics 32EUs, Alder Lake-N i3-N305, 14.00", 1.719 kg
Análise do Asus Expertbook B5 Flip B5402F - Um ótimo conversível com um porém
Iris Xe G7 96EUs, Raptor Lake-P i7-1360P, 14.00", 1.412 kg

Pro

+Funciona silenciosamente
+Baixo consumo de energia
+Esquenta muito pouco


Contra

-Apenas 12 meses de garantia
-Tela de baixo contraste

Asus F551MA-SX063H - 05/01/2014 v4(old)
Sascha Mölck

Acabamento
62 / 98 → 63%
Teclado
67%
Mouse
67%
Conectividade
60 / 80 → 75%
Peso
62 / 20-67 → 89%
Bateria
84%
Pantalha
72%
Desempenho do jogos
34 / 68 → 50%
Desempenho da aplicação
53 / 92 → 58%
Temperatura
92%
Ruído
93%
Audio
50%
Camera
35 / 85 → 41%
Médio
64%
72%
Office - Médio equilibrado
Sascha Mölck, 2014-05-14 (Update: 2014-05-15)
