Intel Atom Z3770

Intel Z3770

O Intel Atom Z3770 é um SoC quad-core energeticamente eficiente para tablets Windows e Android. Ele tem uma frequência de 1,46 - 2,4 GHz e parte da plataforma Bay Trail-T. Graças ao processo especialmente otimizado para baixa energia de 22 nanômetros (P1271) com transistores tri-gate, o desempenho e a eficiência da energia foram significantemente melhorados em comparação com o seu antecessor.

Arquitetura

Os núcleos do processador se baseiam na nova arquitetura Silvermont, que é um design fora de ordem pela primeira vez. O aumento da utilização do pipeline e muitas outras melhorias (previsão de ramo otimizada, buffers aumentados, decodificadores melhorados) aumentaram o desempenho em cerca de 50 por cento. Ao mesmo tempo, no entanto, o recurso Hyper-Threading da geração anterior foi removido. Outras mudanças importantes são o suporte para novas extensões do conjunto de instruções como SSE 4.1 e 4.2, bem como AES-NI (dependendo do modelo).

Desempenho

Graças aos 4 núcleos da CPU e uma frequência de 1,46 - 2,4 GHz, o Z3770 é significantemente mais veloz que anteriores Atoms da Intel, por exemplo, o Z2760. O Z3770 inclusive supera algumas das APUs Kabini como o AMD A4-5000, bem como SoCs ARM, como o Tegra 4 e o Snapdragon 800. Para as tarefas do dia a dia, como Internet ou Escritório, o desempenho é adequado, mas não para software muito complexo ou jogos modernos. Um primeiro benchmark Cinebench R11.5 vazado (infelizmente apenas 32 Bits) coloca o Z3770 no teste multi core em um nível de um Celeron Ivy Bridge de 1,8 GHz.

Gráficos

A HD Graphics (Bay Trail) se baseia na arquitetura Gen7 da Intel, que suporta DirectX 11 e também é encontrada na série Ivy Bridge (por exemplo, HD Graphics 4000). Com apenas 4 EUs (Execution Units) e uma frequência relativamente baixa de até 667 MHz, a GPU é ainda mais lenta que a HD Graphics (Ivy Bridge) e similar à Qualcomm Adreno 320 (como foi observado no Snapdragon 600). Portanto, somente jogos de Windows antigos e menos exigentes poderão rodar fluentemente. No entanto, a aceleração de vídeo e as resoluções de telas de até 2560 x 1600 pixels não são problema para o chip.

Consumo de Energia

Todo o SoC tem um SDP de 2 watts, o que indica um TDP de menos de 4 watts. Por isso o chip pode ser usado em tablets com resfriamento passivo.

SérieIntel Atom
CodinomeBay Trail-T

Serie: Atom Bay Trail-T

Intel Atom Z37951.59 - 2.39 GHz4 / 4 cores
Intel Atom Z37851.49 - 2.41 GHz4 / 4 cores
Intel Atom Z37751.46 - 2.39 GHz4 / 4 cores
Intel Atom Z3775D1.49 - 2.41 GHz4 / 4 cores
Intel Atom Z3770 « 1.46 - 2.4 GHz4 / 4 cores
Intel Atom Z3770D1.5 - 2.41 GHz4 / 4 cores
Intel Atom Z3736F1.33 - 2.16 GHz4 / 4 cores
Intel Atom Z3736G1.33 - 2.16 GHz4 / 4 cores
Intel Atom Z37451.33 - 1.86 GHz4 / 4 cores
Intel Atom Z3745D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z37401.33 - 1.86 GHz4 / 4 cores
Intel Atom Z3740D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735E1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735F1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735G1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z36801.33 - 2 GHz2 / 2 cores
Intel Atom Z3680D1.33 - 2 GHz2 / 2 cores
Frequência1460 - 2400 MHz
Cache de Nível 1224 KB
Cache de Nível 22 MB
Número de Núcelos / Subprocessos4 / 4
Consumo de Energia (TDP = Thermal Design Power)<4 Watt
Tecnologia de Produção22 nm
ConectorUTFCBGA1380
CaracterísticasIntel HD Graphics (Bay Trail, 311 - 667 MHz), Quick Sync, Wireless Display, Clear Video HD, Intel 64, SSE 4.1, SSE 4.2, AES-NI, Secure Key, Anti-Theft, Identify-Protection, max. 4 GB Dual-Channel LPDDR3-1067
GPUIntel HD Graphics (Bay Trail) (311 - 667 MHz)
64 BitSuporte para 64 Bit
Architecturex86
Preço Inicial$37 U.S.
Data do Anúncio09/11/2013
Link do Produto (externo)ark.intel.com

Benchmarks

Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 997     avg: 1158     median: 1189 (7%)     max: 1230 pontos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 2848     avg: 3691     median: 3961 (3%)     max: 4035 pontos
wPrime 2.10 - wPrime 2.0 1024m *
min: 837     avg: 922     median: 862.5 (10%)     max: 1126 s
wPrime 2.10 - wPrime 2.0 32m *
min: 24     avg: 25.9     median: 26.6 (5%)     max: 26.6 s
WinRAR - WinRAR 4.0
898 pontos (1%)
X264 HD Benchmark 4.0 - x264 Pass 2
min: 6.2     avg: 7.8     median: 7.7 (3%)     max: 9.5 fps
X264 HD Benchmark 4.0 - x264 Pass 1
min: 31.5     avg: 39.3     median: 40.5 (9%)     max: 45.9 fps
TrueCrypt - TrueCrypt Serpent
min: 0.077     avg: 0.1     median: 0.1 (0%)     max: 0.123 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.12     avg: 0.2     median: 0.2 (3%)     max: 0.193 GB/s
TrueCrypt - TrueCrypt AES
min: 0.44     avg: 0.8     median: 0.9 (2%)     max: 0.886 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2203     avg: 2212     median: 2212 (5%)     max: 2221 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 27     avg: 33.3     median: 36 (8%)     max: 37 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 61     avg: 74     median: 80 (3%)     max: 81 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 1566     avg: 1686     median: 1735 (8%)     max: 1756 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 15.66     avg: 7984     median: 7984.3 (4%)     max: 15953 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 7.38     avg: 3731     median: 3730.7 (3%)     max: 7454 MFLOPS
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 3379     avg: 4057     median: 4056.5 (4%)     max: 4734 Points
3DMark 11 - 3DM11 Performance Physics
min: 1199     avg: 1353     median: 1330 (4%)     max: 1512 Points
3DMark - 3DMark Ice Storm Physics
min: 11561     avg: 16054     median: 17754 (14%)     max: 18706 Points
3DMark - 3DMark Ice Storm Extreme Physics
min: 17931     avg: 18729     median: 18754 (15%)     max: 19503 Points
3DMark - 3DMark Cloud Gate Physics
min: 956     avg: 1316     median: 1471 (4%)     max: 1555 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 1348     avg: 1748     median: 1748 (3%)     max: 2148 Points
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 2998     avg: 3035     median: 3035 (5%)     max: 3072 pontos
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 977     avg: 981     median: 980.5 (19%)     max: 984 pontos
Geekbench 2 - 32 Bit - Geekbench Stream
min: 2472     avg: 2523     median: 2522.5 (20%)     max: 2573 Points
Geekbench 2 - 32 Bit - Geekbench Memory
min: 2278     avg: 2358     median: 2357.5 (21%)     max: 2437 Points
Geekbench 2 - 32 Bit - Geekbench Floating Point
min: 3092     avg: 3110     median: 3110 (6%)     max: 3128 Points
Geekbench 2 - 32 Bit - Geekbench Integer
min: 3617     avg: 3637     median: 3637 (7%)     max: 3657 Points
Geekbench 2 - 32 Bit - Geekbench Total Score
min: 3063     avg: 3085     median: 3084.5 (8%)     max: 3106 Points
Linpack Android / IOS - Linpack Multi Thread
717 MFLOPS (24%)
Linpack Android / IOS - Linpack Single Thread
265 MFLOPS (26%)
Sunspider - Sunspider 1.0 Total Score *
567 ms (6%)
Sunspider - Sunspider 0.9.1 Total Score *
577 ms (5%)
Quadrant Standard Edition 2.0 - Quadrant Standard 2.0 Total Score
22792 points (53%)
AnTuTu v4 - AnTuTu v4 Total Score
36357 Points (85%)
AndEBench - AndEBench Java
428 Iter./s (13%)
AndEBench - AndEBench Native
21235 Iter./s (70%)
- Gama de valores benchmark para essa solução gráfica
- Média de valores benchmark para essa solução gráfica
* Smaller numbers mean a higher performance
