Intel Celeron N3160

Intel N3160

O Intel Celeron N3160 é um SoC quad-core para portáteis de nível de entrada, que foi apresentado no início de 2016. Ele tem uma frequência de 1,6 - 2,24 GHz (Burst) e parte da plataforma Braswell. É produzido em um modeno processo de 14-nm (P1273) com FinFETs. Além dos quatro núcleos da CPU, o SoC oferece uma GPU com suporte para DirectX 11.2 bem como um Controlador de Memória DDR3L (2x 64 bit, 25,6 GB/s). Em comparação com o Celeron N3150 predecessor, o N3160 tem uma velocidade Burst 160 MHz superior.

Arquitetura

Os núcleos do processador baseiam-se na arquitetura Airmont, que é basicamente uma redução levemente modificada do anterior núcleo Silvermont. Embora o desempenho por núcleo não tenha sido melhorado, o mais eficiente processo de14 nm pode resultar em uma melhor utilização do Burst da CPU (alias Turbo Boost) e, portanto, em um desempenho um pouco superior em certas situações. O desempenho por-MHz ainda é muito inferior em comparação com a série Core mais cara (por exemplo, Broadwell).

Desempenho

Com 4 núcleos de e uma velocidade entre 1,6-2,24 GHz, as especificações técnicas são similares às do anterior Celeron N2930, portanto, o desempenho do processador é apenas um pouco melhor. Isto significa que o processador é apto para tarefas do dia a dia (escritório, navegação) e inclusive as multitarefas leves não devem ser um problema.

Gráficos

A HD Graphics (Braswell) se baseia na arquitetura Gen8 da Intel, que suporta DirectX 11,2 e também é encontrada na série Broadwell (por exemplo, HD Graphics 5300). Com 12 EUs (Unidades de Execução) e uma velocidade de até 640 MHz, no entanto, o desempenho da GPU é muito inferior. Em média, a GPU é quase o dobro de veloz que a HD Graphics (Bay Trail), portanto, é um pouco mais lenta que a antiga HD Graphics 4000. Somente títulos antigos e mais simples como Counter Strike: GO, rodarão fluentemente. O chip ainda inclui uma unidade vídeo avançada com suporte para aceleração de vídeo 4K/H.265.

Consumo de Energia

Todo o SoC tem um TDP de 6 watts (SDP 4 Watts). Por isso o chip, normalmente pode ser resfriado de forma passiva.

SérieIntel Celeron
CodinomeBraswell

Serie: Celeron Braswell

Intel Celeron N3160 « 1.6 - 2.24 GHz4 / 4 cores
Intel Celeron N31501.6 - 2.08 GHz4 / 4 cores
Intel Celeron N30601.6 - 2.48 GHz2 / 2 cores
Intel Celeron N30501.6 - 2.16 GHz2 / 2 cores
Intel Celeron N30001.04 - 2.08 GHz2 / 2 cores
Frequência1600 - 2240 MHz
Cache de Nível 22 MB
Número de Núcelos / Subprocessos4 / 4
Consumo de Energia (TDP = Thermal Design Power)6 Watt
Tecnologia de Produção14 nm
Tempratura Máx.90 °C
ConectorFCBGA1170
CaracterísticasIntel HD Graphics (Braswell, 12 EUs, 320 - 640 MHz), Wireless Display, Quick Sync, AES-NI, max. 8 GB Dual-Channel DDR3L-1600 (25,6 GB/s), 5x USB 3.0, 4x PCIe 2.0, 2x SATA 6.0 Gbit/s
GPUIntel HD Graphics (Braswell) (320 - 640 MHz)
64 BitSuporte para 64 Bit
Architecturex86
Data do Anúncio04/01/2016
Link do Produto (externo)ark.intel.com

Benchmarks

3DMark - 3DMark Ice Storm Unlimited Physics
19687 Points (17%)
3DMark - 3DMark Sling Shot (ES 3.0) Unlimited Physics
1696 Points (19%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
1091 pontos (11%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
3305 pontos (4%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
4300 ms (5%)
Sunspider - Sunspider 1.0 Total Score *
991 ms (11%)
Octane V2 - Octane V2 Total Score
8018 Points (7%)
PCMark for Android - PCM f. Android Computer Vision
3380 Points (18%)
PCMark for Android - PCM f. Android Storage
7992 Points (17%)
PCMark for Android - PCM f. Android Work Score 2.0
5399 Points (35%)
PCMark for Android - PCM f. Android Work Score
7580 Points (38%)
CrXPRT 2 - CrXPRT2 Performance Score
36 Points (20%)
- Gama de valores benchmark para essa solução gráfica
- Média de valores benchmark para essa solução gráfica
* Smaller numbers mean a higher performance
