AMD A10-5745M

AMD A10-5745M

O AMD A10-5745M é um processador quad-core móvel de baixa voltagem baseado na arquitetura Richland. A APU integra dois módulo com 2,1 a 2,9 GHz, uma placa de vídeo Radeon HD 8610G e um controlador de memória DDR3(L)-1333.

Comparado com a Trinity, a Richland foi modificada apenas um pouco. Portanto, nenhuma mudança no conjunto de recursos ou no desempenho Pro-MHz pode ser reportada. O design do chip ainda se baseia na arquitetura Bulldozer, que consiste nos chamados módulos. Cada um dos dois módulos integram 2 unidades de inteiros, mas apenas um FPU. Assim como a Trinity, a Richland suporta praticamente todas as técnicas atuais, como a AVX (incluindo FMA), AES ou Turbo Core.

O desempenho da CPU do A10-5745M deve ser similar ao de um Core i3-2310M. Com isso, a APU é suficiente para a maioria de aplicativos modernos e muitos jogos.

A unidade gráfica chamada Radeon HD 8610G oferece todas as 384 unidades shader (VLIW4) e é um pouco mais veloz que a HD 7660G). O núcleo tem uma frequência de 533-626 MHz (turbo).

O consumo de energia de toda a APU é de 25 watts, que é um pouco mais baixo que o de CPUs comuns de gama média. Portanto, a APU é adequada para portáteis finos de 13 polegadas ou maiores.

SérieAMD A-Series
CodinomeRichland

Serie: A-Series Richland

AMD A10-5750M2.5 - 3.5 GHz4 / 4 cores
AMD A10-5757M2.5 - 3.5 GHz4 / 4 cores
AMD A10-5745M « 2.1 - 2.9 GHz4 / 4 cores
AMD A8-5550M2.1 - 3.1 GHz4 / 4 cores
AMD A8-5557M2.1 - 3.1 GHz4 / 4 cores
AMD A8-5545M1.7 - 2.7 GHz4 / 4 cores
AMD A6-5350M2.9 - 3.5 GHz2 / 2 cores
AMD A6-5357M2.9 - 3.5 GHz2 / 2 cores
AMD A4-5150M2.7 - 3.3 GHz2 / 2 cores
AMD A6-5345M2.2 - 2.8 GHz2 / 2 cores
AMD A4-5145M2 - 2.6 GHz2 / 2 cores
Frequência2100 - 2900 MHz
Cache de Nível 24 MB
Número de Núcelos / Subprocessos4 / 4
Consumo de Energia (TDP = Thermal Design Power)25 Watt
Tecnologia de Produção32 nm
CaracterísticasSSE (1, 2, 3, 3S, 4.1, 4.2, 4A), x86-64, AES, AVX, FMA, DDR3-1333 Controller
GPUAMD Radeon HD 8610G (533 - 626 MHz)
64 BitSuporte para 64 Bit
Architecturex86
Data do Anúncio05/23/2013

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 176     avg: 177     median: 177 (1%)     max: 178 Points
31 -82%
...
Intel Celeron 2970M
164 -7%
Intel Pentium Gold 4425Y
164.5 -7%
168.3 -5%
169.9 -4%
171 -3%
171.7 -3%
AMD A8-7410
172 -3%
175 -1%
176.8 0%
AMD A10-5745M
177
AMD Pro A8-8600B
181 2%
182 3%
Intel Core i5-4302Y
185 5%
187 6%
188 6%
Intel Core m5-6Y57
189.3 7%
Intel Core i3-4030U
189.9 7%
190 7%
Intel Pentium 3825U
190 7%
...
5600 3064%
max:
15842 8850%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 63     avg: 63.5     median: 63.5 (19%)     max: 64 Points
19 -70%
...
55 -13%
55.3 -13%
58 -9%
58.7 -8%
59.1 -7%
59.7 -6%
60 -6%
60 -6%
63 -1%
AMD A10-5745M
63.5
65 2%
Intel Core i5-4302Y
65 2%
65 2%
65.1 3%
65.5 3%
65.5 3%
65.5 3%
Intel Core M-5Y10c
66 4%
Intel Pentium Gold 4425Y
66.6 5%
...
311 390%
max:
332 423%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.91     avg: 1.9     median: 1.9 (2%)     max: 1.93 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 0.66     avg: 0.7     median: 0.7 (17%)     max: 0.72 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 2059     avg: 2065     median: 2065 (12%)     max: 2071 pontos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 5429     avg: 5480     median: 5480 (4%)     max: 5531 pontos
wPrime 2.10 - wPrime 2.0 1024m *
940 s (11%)
wPrime 2.10 - wPrime 2.0 32m *
35 s (7%)
WinRAR - WinRAR 4.0
1585 pontos (3%)
X264 HD Benchmark 4.0 - x264 Pass 2
12.7 fps (4%)
X264 HD Benchmark 4.0 - x264 Pass 1
62.1 fps (14%)
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (0%)
TrueCrypt - TrueCrypt Twofish
0.2 GB/s (4%)
TrueCrypt - TrueCrypt AES
1.1 GB/s (3%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2744     avg: 2753     median: 2745 (6%)     max: 2770 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
34.4 s (7%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
79 s (3%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
2040 s (9%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
6082 Points (5%)
3DMark 11 - 3DM11 Performance Physics
min: 2103     avg: 2190     median: 2155 (6%)     max: 2311 Points
3DMark - 3DMark Ice Storm Physics
min: 20181     avg: 21592     median: 21774 (18%)     max: 22821 Points
3DMark - 3DMark Cloud Gate Physics
min: 1807     avg: 1843     median: 1831 (5%)     max: 1892 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 2576     avg: 2615     median: 2619 (5%)     max: 2651 Points
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 3647     avg: 3724     median: 3724 (7%)     max: 3801 pontos
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 1460     avg: 1476     median: 1476 (29%)     max: 1492 pontos
Geekbench 2 - 32 Bit - Geekbench Stream
3012 Points (24%)
Geekbench 2 - 32 Bit - Geekbench Memory
2483 Points (23%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
5572 Points (11%)
Geekbench 2 - 32 Bit - Geekbench Integer
4319 Points (9%)
Geekbench 2 - 32 Bit - Geekbench Total Score
4259 Points (11%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 4634     avg: 5294     median: 5294 (6%)     max: 5954 ms
Sunspider - Sunspider 1.0 Total Score *
min: 226.8     avg: 243.3     median: 243.3 (3%)     max: 259.8 ms
Octane V2 - Octane V2 Total Score
min: 5708     avg: 6638     median: 6638 (6%)     max: 7568 Points
- Gama de valores benchmark para essa solução gráfica
- Média de valores benchmark para essa solução gráfica
* Smaller numbers mean a higher performance
