Intel Core i7-940XM

Intel 940XM

O Intel Core i7 940XM Extreme Edition é um processador de alto desempenho. O processador mais rápido para portáteis no momento do anúncio. Apresenta 4 núcleos (CPU quad core) e Hyperthreading. Portanto, 8 threads podem funcionar simultaneamente.

Graças ao Modo Turbo, o CPU funciona com uma freqüência de até 3,3 GHz em aplicativos single threaded. Usando dois núcleos, o CPU pode funcionar com até 3,2 GHz e usando os 4 núcleos, 2,4 GHz é a freqüência máxima. Portanto, inclusive jogos antigos (single threaded) devem se executar fluentemente com este CPU móvel embora a freqüência base seja um pouco baixa. O 940XM deve fornecer a suficiente potência para todos os jogos e aplicativos modernos (em 2010).

A linha Core i7 9xx possui um controlador de memória integrado para barras DDR3 (1066 ou 1333). Portanto, o desempenho da memória é muito bom (comparado com CPUs mais antigos com controladores externos de memória). Mesmo assim, isto também leva a um TDP mais alto de todo o chip.

A arquitetura do núcleo ainda é muito semelhante à da usada nos CPUs Core 2.

O consumo de energia de até 55 Watt (TDP) é bastante alto para um CPU de portátil e por causa do Modo Turbo, o consumo de energia deve atingir estes valores altos.

SérieIntel Core i7
CodinomeClarksfield

Serie: Core i7 Clarksfield

Intel Core i7-940XM « 2.13 - 3.33 GHz4 / 8 cores8 MB L3
Intel Core i7-920XM2 - 3.2 GHz4 / 8 cores8 MB L3
Intel Core i7-840QM1.86 - 3.2 GHz4 / 8 cores8 MB L3
Intel Core i7-820QM1.73 - 3.06 GHz4 / 8 cores8 MB L3
Intel Core i7-740QM1.73 - 2.93 GHz4 / 8 cores6 MB L3
Intel Core i7-720QM1.6 - 2.8 GHz4 / 8 cores6 MB L3
Frequência2130 - 3333 MHz
Barramento Frontal2500
Cache de Nível 1256 KB
Cache de Nível 21 MB
Cache de Nível 38 MB
Número de Núcelos / Subprocessos4 / 8
Consumo de Energia (TDP = Thermal Design Power)55 Watt
Contagem de transistores774 Milhão
Tecnologia de Produção45 nm
Tamanho da Matriz296 mm2
Tempratura Máx.100 °C
ConectorRPGA989
Características2.5 GT/s DMI, Virtualization Technology, Execute Disable Bit, Enahnced Speedstep Technology, Enhanced Halt State (C1E), 64, Turbo Boost (max. 3.33 GHz), Hyper-Threading, Trusted Execution Technology
64 BitSuporte para 64 Bit
Architecturex86
Preço Inicial$1096 U.S.
Data do Anúncio06/01/2010
Link do Produto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.65     avg: 3.9     median: 3.9 (5%)     max: 4.05 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
3630 pontos (22%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
11391 pontos (8%)
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 12642     avg: 13381     median: 13381 (9%)     max: 14120 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 4479     avg: 4488     median: 4488 (5%)     max: 4497 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 374     avg: 798     median: 798 (9%)     max: 1222 s
wPrime 2.10 - wPrime 2.0 32m *
min: 12     avg: 25.2     median: 25.2 (5%)     max: 38.36 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3884     avg: 4080     median: 4064 (9%)     max: 4293 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
12 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
28 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 699     avg: 700     median: 700 (3%)     max: 701 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
62380 MIPS (30%)
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
40660 MFLOPS (31%)
Windows 7 Experience Index - Win7 CPU
7.3 Points (94%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
13326 Points (12%)
- Gama de valores benchmark para essa solução gráfica
- Média de valores benchmark para essa solução gráfica
* Smaller numbers mean a higher performance
