Intel Core i7-3940XM

Intel 3940XM

O Intel Core i7-3940XM é o processador quad-core mais veloz para portáteis (no momento da introdução em Setembro de 2012) um sucessor do i7-3920XM. Graças ao Hyperthreading, os quatro núcleos podem suportar até oito threads em paralelo fazendo uma melhor utilização do CPU. Cada núcleo oferece uma velocidade base de 3,0 GHz, mas pode aumentar a freqüência dinamicamente com Turbo Boost, até 3,7 GHz (para 4 núcleos ativos), 3,8 GHz (para 2 núcleos ativos) e 3,9 GHz (para 1 núcleo ativo). Além disso, os CPUs Extreme oferecem um multiplicador desbloqueado para a fácil aceleração (overclocking).

Ivy Bridge é uma matriz aprimorada e reduzida da arquitetura Sandy Bridge com melhorias no desempenho do GPU e CPU. Os CPUs são produzidos em 22nm (contra 32nm dos CPUs Sandy Bridge) e são os primeiros em introduzir transistores 3D para uma maior eficiência energética quando comparado com processadores Sandy Bridge com frequências similares. Outros novos recursos são o PCI Express 3.0 integrado e suporte para DDR3(L)-1600.

O desempenho do Core i7-3940XM deve ser ligeiramente superior que o de um processador Sandy Bridge com frequência similar graças a ligeiras alterações estruturais. Devido à maior frequência, o ex-campeão, Core i7-3920XM, deve ser superado por cerca de 3%.

O Intel HD Graphics 4000 integrado, oferece 16 Unidades de Execução (EUs) com frequência de 650 MHz até 1350 MHz com Turbo Boost, tornando-o a variante mais rápida.

Os CPUs XM estão classificados em um TDP de 55 Watts incluindo a placa de vídeo e controlador de memória e, portanto, 10 Watts mais alto que os outros modelos quad-core.  Portanto, o CPU é bem adequado para portáteis de 17 polegadas ou maiores.

SérieIntel Core i7
CodinomeIvy Bridge
Serie: Core i7 Ivy Bridge
» Intel Core i7-3940XM3 - 3.9 GHz4 / 88 MB
Intel Core i7-3920XM2.9 - 3.8 GHz4 / 88 MB
Intel Core i7-3840QM2.8 - 3.8 GHz4 / 88 MB
Intel Core i7-3820QM2.7 - 3.7 GHz4 / 88 MB
Intel Core i7-3740QM2.7 - 3.7 GHz4 / 86 MB
Intel Core i7-3720QM2.6 - 3.6 GHz4 / 86 MB
Intel Core i7-3635QM2.4 - 3.4 GHz4 / 86 MB
Intel Core i7-3630QM2.4 - 3.4 GHz4 / 86 MB
Intel Core i7-3615QM2.3 - 3.3 GHz4 / 86 MB
Intel Core i7-3610QM2.3 - 3.3 GHz4 / 86 MB
Intel Core i7-3632QM2.2 - 3.2 GHz4 / 86 MB
Intel Core i7-3612QM2.1 - 3.1 GHz4 / 86 MB
Intel Core i7-3540M3 - 3.7 GHz2 / 44 MB
Intel Core i7-3520M2.9 - 3.6 GHz2 / 44 MB
Intel Core i7-3687U2.1 - 3.3 GHz2 / 44 MB
Intel Core i7-3667U2 - 3.2 GHz2 / 44 MB
Intel Core i7-3537U2 - 3.1 GHz2 / 44 MB
Intel Core i7-3517U1.9 - 3 GHz2 / 44 MB
Intel Core i7-3689Y1.5 - 2.6 GHz2 / 44 MB
Frequência3000 - 3900 MHz
Cache de Nível 1256 KB
Cache de Nível 21 MB
Cache de Nível 38 MB
Número de Núcelos / Subprocessos4 / 8
Consumo de Energia (TDP = Thermal Design Power)55 Watt
Contagem de transistores1400 Milhão
Tecnologia de Produção22 nm
Tamanho da Matriz160 mm2
Tempratura Máx.105 °C
ConectorFCPGA988
CaracterísticasHD Graphics 4000, DDR3(L)-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1350 MHz)
64 BitSuporte para 64 Bit
Architecturex86
Preço Inicial$1096 U.S.
Data do Anúncio09/30/2012

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 7.45     avg: 7.5     median: 7.5 (15%)     max: 7.46 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.62     avg: 1.6     median: 1.6 (52%)     max: 1.63 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 5246     avg: 5255     median: 5252 (47%)     max: 5267 pontos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 20438     avg: 20582     median: 20564 (33%)     max: 20744 pontos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 25475     avg: 25600     median: 25624 (24%)     max: 25700 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 6506     avg: 6621     median: 6669 (47%)     max: 6687 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 208.8     avg: 219     median: 215.7 (3%)     max: 233 s
wPrime 2.10 - wPrime 2.0 32m *
min: 6.8     avg: 7     median: 7 (1%)     max: 7.169 s
WinRAR - WinRAR 4.0
min: 3467     avg: 4124     median: 4123.5 (26%)     max: 4780 pontos
X264 HD Benchmark 4.0 - x264 Pass 2
40.6 fps (18%)
X264 HD Benchmark 4.0 - x264 Pass 1
161 fps (47%)
TrueCrypt - TrueCrypt Serpent
min: 0.373     avg: 0.4     median: 0.4 (16%)     max: 0.386 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.64     avg: 0.7     median: 0.7 (18%)     max: 0.66 GB/s
TrueCrypt - TrueCrypt AES
min: 3.5     avg: 3.6     median: 3.7 (14%)     max: 3.7 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 7166     avg: 7182     median: 7176 (40%)     max: 7203 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 9     avg: 9.2     median: 9 (2%)     max: 9.554 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 21     avg: 21.1     median: 21 (1%)     max: 21.256 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 518     avg: 526     median: 525.5 (2%)     max: 533 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 147240     avg: 147620     median: 147620 (70%)     max: 148000 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 89600     avg: 89630     median: 89630 (69%)     max: 89660 MFLOPS
Windows 7 Experience Index - Win7 CPU
7.7 Points (99%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 25344     avg: 25795     median: 25885 (30%)     max: 26157 Points
3DMark 11 - 3DM11 Performance Physics
min: 7611     avg: 8737     median: 9032 (33%)     max: 9568 Points
3DMark - 3DMark Ice Storm Physics
48410 Points (31%)
3DMark - 3DMark Cloud Gate Physics
7208 Points (18%)
3DMark - 3DMark Fire Strike Standard Physics
9863 Points (25%)
- Gama de valores benchmark para essa solução gráfica
- Média de valores benchmark para essa solução gráfica
* Smaller numbers mean a higher performance
