ATI Mobility Radeon HD 2300

ATI Mobility Radeon HD 2300

A placa de vídeo Mobility Radeon HD 2300 para portáteis é a sucessora da X1300 e suporta somente DirectX9 (de acordo com as informações da homepage AMD). O desempenho deverá ser um pouco maior que o X1300 e, portanto média ou pior desempenho de jogos. AMD / ATI diz que a relação do desempenho/Watt foi melhorada. Rumores dizem que o chip é apenas um chip de vídeo X1300 / X1350 renomeado.

Uma diferença com a X2300 são as opções de vídeo amplificadas (UVD).

O processador gráfico HD 2300 está certificado para Windows Vista e suporta a Interface Windows Aero Glass.

fabricanteATI
CódigoM71
ArquiteturaRV5xx
Pipelines4 / 2 Pixel- / Vertexshader
Velocidade do núcleo480 MHz
Velocidade da memória400 MHz
Largura do Bus de Memória128 Bit
Modelo de memóriaDDR1/DDR2/GDDR3
Memória compartilhadanão
DirectXDirectX 9c, Shader 3.0
Contagem de transistores115 Milhão
tecnología90 nm
CaracterísticasProcesso de manufatura 90nm, PCI Express X16 Interface, PowerPlay 6.0, arquitetura de vídeo Avivo (MPEG-2, MPEG-4, DivX, WMV9, aceleração VC-1), 64-bit floating point HDR, Ultra-Threaded Shader Engine, OpenGL 2.0
Data do anúncio01.03.2007
Link à página do Fabricantehttp://ati.amd.com/products/MobilityRade...

Benchmarks

3DMark 05 - Standard 1024x768
1902 Points (4%)
3DMark 06 +
- Gama de valores benchmark para essa solução gráfica
- Média de valores benchmark para essa solução gráfica
* Smaller numbers mean a higher performance

Para mais jogos compatíveis e uma lista de todos os jogos e soluções gráficas visite nosso Lista de jogos
v1.6b1

Análises de Portáteis com ATI Mobility Radeon HD 2300 Placa de vídeo

Sony Vaio VGN-BX41VN: Intel Core 2 Duo T7300, 15.4", 3 kg
  ánalise externa » Sony Vaio VGN-BX41VN

Sony Vaio VGN-CR11Z: Intel Core 2 Duo T7100, 14.1", 2.5 kg
  ánalise externa » Sony Vaio VGN-CR11Z

Sony Vaio VGN-CR21Z: Intel Core 2 Duo T7250, 14.1", 2.5 kg
  ánalise externa » Sony Vaio VGN-CR21Z
