AMD Radeon RX Vega 8 (Ryzen 4000)

AMD Vega 8 R4000

A AMD Radeon RX Vega 8 é uma GPU integrada para portáteis. É usada para as 7 APUs Ryzen da geração Renoir (Ryzen 4000 Mobile), anunciadas no início de 2020. A GPU é baseada na arquitetura Vega (GCN de 5ª geração) e possui 8 CUs (= 512 dos 704 shaders) com velocidade de até 1,750 MHz (Ryzen 7 4800U). O desempenho depende do TDP configurado (12-25 W na inicialização), as velocidades, do resfriamento e da configuração da memória). A GPU deve se beneficiar da rápida RAM DDR4-3200 dual-channel (ao contrário da DDR4-2133 single-channel, que também é possível). Comparada com a Radeon RX Vega 8 semelhante na geração Raven Ridge (Ryzen 2000 Mobile), a GPU tem uma velocidade significativamente maior (1.750 versus 1.100 MHz Boost, + 59%).

A arquitetura Vega oferece algumas melhorias sobre a geração Polaris e agora suporta o DirectX 12 Feature Level 12_1. Mais informações estão disponíveis em nosso artigo dedicado sobre a arquitetura Raven Ridge.

O desempenho é claramente mais rápido que o da antiga RX Vega 8, graças à maior velocidade e à memória principal mais rápida (se usada). Ainda está posicionada no nível básico (comparado às placas gráficas dedicadas) e é adequada apenas para jogos pouco exigentes.

Graças ao moderno processo de 7nm e recursos inteligentes de economia de energia, o consumo de energia é comparativamente baixo (de acordo com a AMD), portanto, a placa de vídeo também pode ser usada para portáteis finos e leves.

fabricanteAMD
AMD Radeon RX Vega 4000 Serie
Vega 8 R4000 512 @ 1.75 GHz
Vega 7 448 @ 1.6 GHz
Vega 5 320 @ 1.4 GHz
CódigoVega Raven Ridge
ArquiteturaVega
Pipelines512 - unificado
Velocidade do núcleo1750 (Boost) MHz
Memória compartilhadanão
DirectXDirectX 12_1
tecnología7 nm
CaracterísticasTiled Rasterization, Shared Memory (up to Dual-Channel DDR4-2400)
Data do anúncio07.01.2020
CPU in Vega 8 R4000GPU Base SpeedGPU Boost / Turbo
AMD Ryzen 9 5980HX8 x 3300 MHz, 45 W? MHz2100 MHz
AMD Ryzen 9 5900HX8 x 3300 MHz, 45 W? MHz2100 MHz
AMD Ryzen 9 5980HS8 x 3300 MHz, 35 W? MHz2100 MHz
min. - max.? MHz1750 - 2100 MHz

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
15 pt (16%)
AMD Radeon HD 8180 -91%
...
Intel Iris Xe Graphics G7 96EUs -5%
AMD FirePro W5170M -4%
NVIDIA Quadro P600 -2%
NVIDIA Quadro M3000M -1%
AMD Radeon RX Vega 8 (Ryzen 4000)
NVIDIA Quadro P620 1%
...
AMD Radeon RX 6800 XT 522%
0%
100%
3DMark - 3DMark Time Spy Score
min: 1187     avg: 1342     median: 1291 (7%)     max: 1598 Points
3DMark - 3DMark Time Spy Graphics
min: 1040     avg: 1193     median: 1154.5 (6%)     max: 1400 Points
Intel UHD Graphics 600 -91%
...
AMD Radeon RX 550X (Laptop) -12%
AMD Radeon Pro 555 -10%
AMD Radeon Pro 455 -6%
NVIDIA Quadro P600 -3%
Intel Iris Xe Graphics G7 80EUs -2%
AMD Radeon RX Vega 8 (Ryzen 4000)
AMD Radeon Pro 560 15%
NVIDIA Quadro P620 16%
NVIDIA Quadro P1000 17%
Intel Iris Xe Graphics G7 96EUs 20%
AMD Radeon Pro 560X 35%
NVIDIA GeForce GTX 1050 Max-Q 35%
...
NVIDIA GeForce RTX 3080 Ti 1499%
0%
100%
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 186037     avg: 240113     median: 198052 (31%)     max: 321196 Points
3DMark - 3DMark Ice Storm Extreme Graphics
min: 92720     avg: 103582     median: 100035 (14%)     max: 121538 Points
3DMark - 3DMark Cloud Gate Score
min: 19575     avg: 23096     median: 22950 (30%)     max: 28638 Points
3DMark - 3DMark Cloud Gate Graphics
min: 25553     avg: 28210     median: 27160 (13%)     max: 33672 Points
3DMark - 3DMark Fire Strike Standard Score
min: 3089     avg: 3508     median: 3479.5 (9%)     max: 4040 Points
3DMark - 3DMark Fire Strike Standard Graphics
min: 3430     avg: 3864     median: 3840 (8%)     max: 4462 Points
3DMark - 3DMark Ice Storm Graphics
min: 123789     avg: 147881     median: 128664 (17%)     max: 210406 Points
3DMark - 3DMark Night Raid
min: 13199     avg: 14984     median: 14513 (21%)     max: 17709 Points
3DMark - 3DMark Night Raid Graphics Score
min: 13637     avg: 15920     median: 15638.5 (10%)     max: 18765 Points
3DMark 11 - 3DM11 Performance Score
min: 5592     avg: 6273     median: 6362.5 (15%)     max: 7348 Points
3DMark 11 - 3DM11 Performance GPU
min: 5373     avg: 6096     median: 6171.5 (10%)     max: 7033 Points
...
NVIDIA Quadro P620 -3%
NVIDIA Quadro P1000 -1%
NVIDIA GeForce GTX 580 -1%
NVIDIA GeForce GTX 775M 0%
AMD Radeon RX Vega 8 (Ryzen 4000)
AMD Radeon HD 7870 2%
Intel Iris Xe Graphics G7 96EUs 5%
AMD Radeon Pro 460 11%
...
NVIDIA GeForce RTX 3080 Ti 905%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
20018 Points (20%)
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
16657 Points (15%)
...
NVIDIA GeForce GTX 470 -8%
NVIDIA Quadro P520 -7%
AMD Radeon HD 6870 -2%
AMD Radeon RX Vega 8 (Ryzen 4000)
NVIDIA GeForce GTX 560 Ti 6%
AMD Radeon Pro 460 6%
AMD Radeon Pro 560 7%
...
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
22966 Points (43%)
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 11122     avg: 11329     median: 11328.5 (53%)     max: 11535 pontos
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 61.6     avg: 63.3     median: 63.3 (27%)     max: 64.93 fps
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 64.3     avg: 74.6     median: 73.1 (21%)     max: 88.15 fps
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
98 % (98%)
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
572 Samples/s (6%)
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
1030 Samples/s (3%)
ComputeMark v2.1 - ComputeMark v2.1 Result
3498 pontos (7%)
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
min: 30.3     avg: 37.6     median: 39.6 (7%)     max: 42.8 Watt
0510152025303540455037.840.537.941.640.352.150.540.139.243.239.337.737.93937.637.937.83852.843.339.241.942.437.840.942.938.342.642.641.742.244.541.53841.540.137.942.540.337.742.240.537.737.640.237.737.93838.238.238.43837.839.937.938.138.838.238.138.638.237.736.937.436.837.33740.437.337.542.336.934.92424.124.323.924.223.924.124.324.224.324.424.124.124.124.123.824.124.224.124.124.623.824.12423.824.123.524.12423.823.82423.923.92424.324.224.124.123.723.924.123.823.923.723.82423.823.62423.923.523.823.823.823.824.124.123.823.723.523.923.824.123.823.623.523.923.82423.323.723.923.523.623.723.623.823.623.823.823.823.823.423.623.523.623.923.923.923.923.823.523.723.724.123.6242423.72423.623.623.723.623.924.323.623.524.724.624.424.324.125.425.223.92424.624.124.625.224.825.624.250.147.851.348.643.940.539.64040.140.239.840.239.639.839.84040.14040.640.840.939.74140.240.54140.740.540.540.540.240.24040.140.34040.139.940.54040.34040.139.940.140.340.340.740.64040.140.540.240.640.240.240.140.240.240.640.540.240.240.340.740.240.240.840.140.540.340.740.440.740.640.640.741.541.341.140.840.840.84141.241.540.940.741.441.141.541.84140.941.140.640.641.140.940.540.340.440.840.740.540.740.340.44140.640.540.840.640.640.641.240.740.740.540.641.141.440.740.841.240.740.741.241.140.741.140.7414140.741.242.141.541.741.241.240.941.54241.34141.341.140.940.940.741.341.641.14140.940.94141.341.241.341.440.940.940.941.341.441.54141.74141.741.64141.1Tooltip
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
min: 30.8     avg: 42.8     median: 46.7 (8%)     max: 50.9 Watt
05101520253035404550556023.923.72423.923.923.823.824.32424.124.22424.123.924.123.923.924.423.823.723.824.123.723.624.224.523.823.923.82423.823.924.123.723.623.623.823.6242423.623.823.823.723.723.523.724.12423.923.724.223.723.824.223.82423.923.823.723.823.923.723.923.923.923.923.623.923.923.7242423.522.622.823.32322.823.122.922.723.222.822.623.322.822.722.522.722.822.421.635.837.137.135.837.736.336.836.737.136.436.637.337.636.637.840.136.738.940.737.139.240.437.240.540.740.740.640.34040.741.438.53740.838.337.74137.937.937.738.337.537.337.63837.437.137.837.937.737.837.537.53837.537.137.638.937.337.74137.737.740.93841.341.239.34140.838.941.440.938.541.241.338.337.840.637.83839.937.838.238.13851.451.451.15151.551.149.251.350.450.350.551.752.349.350.350.651.159.758.451.249.951.650.251.452.449.750.651.950.751.549.850.250.851.150.850.351.250.751.25051.351.550.251.151.151.350.750.850.950.250.951.150.949.950.450.550.951.150.750.752.150.152.150.450.851.350.151.55149.85150.249.950.549.950.849.950.551.75151.35150.351.356.350.86050.951.75150.651.351.35152.451.150.151.550.950.852.149.651.351.25150.550.850.950.45150.750.850.750.75150.550.350.950.150.150.851.151.650.950.751.45152.352.450.650.951.750.651.251.550.651.750.650.250.95149.850.251.15152.550.15050.550.850.350.85150.55150.249.950.851.950.151.150.65050.849.950.151.250.452.350.550.250.450.151.55050.550.850.450.950.849.751.251.850.450.649.949.951.649.650.150.850.15050.349.550.250.650.850.150.951.550.750.950.450.750.450.450.550.451.251.251.251.249.950.749.95050.850.751.250.251.651.149.651.150.349.751.249.850.350.850.151.25150.450.850.750.950.65050.350.750.851.150.750.250.951.15150.1Tooltip
Power Consumption - Witcher 3 Power Consumption *
min: 40.8     avg: 45.5     median: 43.2 (9%)     max: 54.4 Watt
051015202530354045505541.941.543.242.141.94245.843.942.542.144.941.252.143.442.542.149.349.542.644.143.242.442.843.842.343.443.143.345.74343.143.642.242.143.543.242.242.342.342.443.242.24241.541.941.944.142.341.942.14241.642.141.941.742.341.842.742.24242.94341.741.541.341.941.141.841.644.242.541.341.241.943.242.741.741.54142.342.242.441.441.841.541.441.241.541.542.541.641.441.641.141.241.141.741.242.241.941.441.440.240.942.341.641.240.740.540.942.841.341.541.44142.947.141.441.847.842.141.541.441.940.641.741.441.441.841.741.342.944.241.340.54141.541.240.941.741.14141.240.641.341.143.742.140.74141.341.141.341.341.641.341.141.741.440.541.941.543.541.740.840.841.242.441.340.741.241.44141.440.741.441.441.340.741.141.540.941.141.840.840.940.742.540.841.342.141.544.841.141.341.341.441.144.64342.543.843.642.442.742.742.142.442.242.942.542.342.442.442.642.342.442.442.342.543.142.742.842.744.842.944.444.946.144.544.945.94546.344.146.447.344.34646.143.84346.443.642.645.442.542.542.642.843.242.743.542.241.842.141.842.143.54243.242.441.641.641.641.642.141.641.74341.641.744.744.842.444.845.141.944.544.644.244.84543.645.745.342.841.544.741.742.344.441.941.64242.141.542.241.741.542.542.542.544.141.444.842.441.341.441.641.941.742.241.941.541.841.742.142.942.242.64242.142.242.442.342.741.642.74242.243.441.741.644.545.242.145.641.642.24242.442.141.741.741.641.542.241.441.842.14241.442.442.742.142.643.342.142.241.442.142.144.641.94244.343.145.245.444.345.145.344.444.64541.941.941.341.842.241.641.842.24241.94241.942.442.342.142.141.942.942.242.843.445.14244.54542.44545.14645.646.345.64246.344.543.943.442.241.842.442.154.953.554.352.752.853.95253.854.752.654.354.754.653.754.9545355.453.653.554.854.455.358.354.957.155.453.95453.254.355.254.452.754.253.854.354.655.252.85454.353.555.154.454.25354.255.653.955.254.35453.253.952.85453.354.453.553.254.453.752.955.853.852.753.955.255.254.352.854.754.755.85454.854.554.354.75556.254.554.153.454.455.254.854.655.355.155.353.955.955.755.553.753.454.954.35354.255.154.253.453.654.655.854.154.45554.255.853.8565554.653.153.154.854.754.954.255.154.955.354.155.255.654.153.253.154.555.254.953.953.154.254.454.654.255.154.953.552.853.454.954.754.853.953.352.954.154.755.454.453.653.354.75554.653.554.455.555.154.153.453.155.555.354.454.654.35554.754.354.25554.855.355.35554.754.554.456.155.155.454.854.754.453.7555554.453.55353.55455.355.654.85554.855.854.853.853.753.755.654.655.35555.155.455.954.653.452.954.553.454.155.154.755.154.355.455.654.854.453.753.75355.255.254.754.553.553.35554.3Tooltip
- Gama de valores benchmark para essa solução gráfica
- Média de valores benchmark para essa solução gráfica
* Smaller numbers mean a higher performance

Benchmarks de jogos

Os seguintes benchmarks têm origem em nossos benchmarks de portáteis de análise O desempenho depende da memória gráfica utilizada, frequência, processador, configurações do sistema, controladores, e sistemas operacionais. Assim os resultados não tem que representantes para todos os portáteis com esta GPU. Para informações detalhadas sobre os resultados de benchmark, clique no número de fps.

F1 2021

F1 2021

2021
baixo 1280x720
94  fps    + Comparar
média 1920x1080
42  fps    + Comparar
alto 1920x1080
32  fps    + Comparar
» Jogável em configuração de detalhes com todos os notebooks testados média.
Additional Benchmarks
Ultra Low Preset 1920x1080
57
Days Gone

Days Gone

2021
baixo 1280x720
33.8 fps 46.8 fps ~ 40 fps    + Comparar
média 1920x1080
18.2 fps 23.9 fps ~ 21 fps    + Comparar
alto 1920x1080
16.9 fps 21.3 fps ~ 19 fps    + Comparar
ultra 1920x1080
12.8 fps 16.4 fps ~ 15 fps    + Comparar
QHD 2560x1440
11.1 fps  fps    + Comparar
» Jogável em configuração de detalhes com a maioria dos notebooks testados baixo.
Additional Benchmarks
Low Preset 1920x1080
28.9 fps
Mass Effect Legendary Edition

Mass Effect Legendary Edition

2021
baixo 1280x720
45.6 fps 49.4 fps ~ 48 fps    + Comparar
ultra 1920x1080
33.4 fps 33.5 fps ~ 33 fps    + Comparar
QHD 2560x1440
21.9 fps  fps    + Comparar
» Jogável em configuração de detalhes com todos os notebooks testados baixo.
Resident Evil Village

Resident Evil Village

2021
baixo 1280x720
58.3 fps  fps    + Comparar
média 1920x1080
27.8 fps  fps    + Comparar
alto 1920x1080
27.1 fps  fps    + Comparar
ultra 1920x1080
24.2 fps  fps    + Comparar
QHD 2560x1440
15 fps  fps    + Comparar
» Jogável em configuração de detalhes com todos os notebooks testados baixo.
Additional Benchmarks
Prioritize Performance Preset 1920x1080
33.6 fps
Outriders

Outriders

2021
baixo 1280x720
39.9 fps 60.4 fps ~ 50 fps    + Comparar
média 1920x1080
29 fps 29.5 fps ~ 29 fps    + Comparar
alto 1920x1080
21.9 fps 28.8 fps ~ 25 fps    + Comparar
ultra 1920x1080
16.7 fps 24.2 fps ~ 20 fps    + Comparar
QHD 2560x1440
17.1 fps  fps    + Comparar
» Jogável em configuração de detalhes com todos os notebooks testados baixo.
Additional Benchmarks
Low Preset 1920x1080
33.9 fps
30.4 fps
Hitman 3

Hitman 3

2021
baixo 1280x720
55.3 80.2 ~ 68 fps    + Comparar
média 1920x1080
19.6 29.8 ~ 25 fps    + Comparar
alto 1920x1080
17.6 26.6 ~ 22 fps    + Comparar
ultra 1920x1080
16.1 24.6 ~ 20 fps    + Comparar
QHD 2560x1440
15.1  fps    + Comparar
» Jogável em configuração de detalhes com todos os notebooks testados baixo.
Additional Benchmarks
Minimum Settings 1920x1080
42.5 fps
28.9 fps
baixo 1280x720
35.9 fps
